Description
- Hinges are adjustable and self-closing.
- Made from glass-fiber reinforced polymer (UV stabilized).
- Will not rust and never needs lubrication.
- No visible fasteners once included screw cover plates are installed
- Spring tension is incrementally adjustable with a screwdriver.
- Self-closes light to medium gates up to 66lbs per pair of hinges.
- Weight rating is based on gate maximum size of 5′ high by 3′ wide.
- These hinges have been independently tested to comply with strict safety standards, especially those relating to stringent swimming pool safety codes (always check with your building department for your local building code requirements).
Wood/Vinyl Model:
- For wood or vinyl gates.
- Hinge measures 3-25/32″ tall by 5-3/16″ wide.
- Requires six #10 pan head screws per hinge (not included).
- The White finish comes with Alignment Legs and is not available without them.
- Alignment Legs will fix the gap between the gate and post and offer slightly more stability, see the Dimensional Diagram HERE.
- All of our models here can be special ordered with Alignment Legs, call or email our office to get a quote.
Metal Model:
- For gates made from metal square tubing.
- Hinge measures 3-25/32″ tall by 3-1/32″ wide.
- Requires four #10 pan head screws per hinge (not included).
C10584
